Victron Energy BlueSolar PWM Light 12/24V Charge Controller – 30A

High-Capacity PWM Controller for Larger Solar Arrays

The Victron BlueSolar PWM Light 30A is the highest-capacity model in the PWM Light range, suitable for larger off-grid solar systems running 12V or 24V batteries. It is ideal for campervans, caravans, boats and cabins requiring higher solar input without the complexity of MPPT controllers.

It delivers reliable battery charging with essential safety features to protect both batteries and connected loads.

Key Features

• Supports 12V and 24V battery systems
• 30 amp PWM charge controller for larger solar installations
• Automatic three-stage charging
• Load output with low-voltage disconnect
• Lighting control and timer functionality
• Full protection against overload and wiring faults

Technical Specifications:

Battery Voltage:

12/24 V with automatic system voltage detection;Rated Charge Current=30 amp"

Automatic Load Disconnect:

yes

Protection Battery:

reverse polarity (fuse), output short circuit, over temperature

Low Voltage Load Disconnect:

11.2V / 22.4V

Low Voltage Load Reconnect:

12.6V / 25.2V (manual), 13.1V / 26.2V (automatic)

Protection Class:

IP20

Terminal Size:

5 mm² (AWG10)

Weight:

0.2 kg

Dimensions D (mm):

70

Dimensions W (mm):

133

Dimensions D (mm):

33.5
